SMB Series(DO-214AA)

Name: SMBJ3.3A SMBJ3.3CA
Brand: Shanghai Leiditech上海雷卯电子科技有限公司是专业的静电保护元件厂家,TVS二极管供应商;专业提供防雷防静电方案,电磁兼容EMC免费测试等服务,品质保证,库存充足,型号齐全,值得信赖,如有采购静电保护元件,TVS二极管需求,请联系雷卯,24小时服务热线:021-50828806.
SKU: 09457
Availability: InStock
Rating: 5 (1 reviews)

Главная > TVS диод подавления переходного напряжения > SMB Series(DO-214AA)

Особенности/приложения Показ одной модели Ищи замену.

Особенности/приложения

DESCRIPTION:

TVS diodes can be used in a wide range of applications

which like consumer electronic products, automotive

industries, munitions, telecommunications, aerospace

industries, and intelligent control systems.

FEATURES:

Glass passivated or planar junction

Excellent clamping capability

Repetition rate (duty cycle): 0.01%

Typical IR less than 1μA above 10V.

Low profile package and low inductance

600W Peak Pulse power capability at 10x1000us waveform.

Fast response time: typically less than 1.Ops from 0V to Vbr min.

High temperature soldering: 260°C/10s at terminals.

Plastic package has Underwriters Laboratory Flammability 94V-0.

For surface mounted applications in order to optimize board space

Показ одной модели

SMBJ3.3A SMBJ3.3CA 600 3.3 150 4.20 6.55 1 8.7 69.1 SMB

SMBJ5.0A SMBJ5.0CA 600 5.0 300 6.40 7.00 10 9.2 65.2 SMB

SMBJ6.0A SMBJ6.0CA 600 6.0 150 6.67 7.37 10 10.3 58.3 SMB

SMBJ6.5A SMBJ6.5CA 600 6.5 100 7.22 7.98 10 11.2 53.6 SMB

SMBJ7.0A SMBJ7.0CA 600 7.0 50 7.78 8.60 10 12.0 50.0 SMB

SMBJ7.5A SMBJ7.5CA 600 7.5 50 8.33 9.21 1 12.9 46.5 SMB

SMBJ8.0A SMBJ8.0CA 600 8.0 35 8.89 9.83 1 13.6 44.1 SMB

SMBJ8.5A SMBJ8.5CA 600 8.5 10 9.44 10.40 1 14.4 41.7 SMB

SMBJ9.0A SMBJ9.0CA 600 9.0 5 10.00 11.10 1 15.4 39.0 SMB

SMBJ10A SMBJ10CA 600 10.0 2 11.10 12.30 1 17.0 35.3 SMB

SMBJ11A SMBJ11CA 600 11.0 1 12.20 13.50 1 18.2 33.0 SMB

SMBJ12A SMBJ12CA 600 12.0 1 13.30 14.70 1 19.9 30.2 SMB

SMBJ13A SMBJ13CA 600 13.0 1 14.40 15.90 1 21.5 27.9 SMB

SMBJ14A SMBJ14CA 600 14.0 1 15.60 17.20 1 23.2 25.9 SMB

SMBJ15A SMBJ15CA 600 15.0 1 16.70 18.50 1 24.4 24.6 SMB

SMBJ16A SMBJ16CA 600 16.0 1 17.80 19.70 1 26.0 23.1 SMB

SMBJ17A SMBJ17CA 600 17.0 1 18.90 20.90 1 27.6 21.8 SMB

SMBJ18A SMBJ18CA 600 18.0 1 20.00 22.10 1 29.2 20.6 SMB

SMBJ20A SMBJ20CA 600 20.0 1 22.20 24.50 1 32.4 18.6 SMB

SMBJ22A SMBJ22CA 600 22.0 1 24.40 26.90 1 35.5 16.9 SMB

SMBJ24A SMBJ24CA 600 24.0 1 26.70 29.50 1 38.9 15.4 SMB

S-SMBJ24A S-SMBJ24CA 600 24.0 1 26.70 29.50 1 38.9 15.4 SMB 车用

SMBJ26A SMBJ26CA 600 26.0 1 28.90 31.90 1 42.1 14.3 SMB

SMBJ28A SMBJ28CA 600 28.0 1 31.10 34.40 1 45.4 13.2 SMB

SMBJ30A SMBJ30CA 600 30.0 1 33.30 36.80 1 48.4 12.4 SMB

SMBJ33A SMBJ33CA 600 33.0 1 36.70 40.60 1 53.3 11.3 SMB

S-SMBJ33A S-SMBJ33CA 600 33.0 1 36.70 40.60 1 53.3 11.3 SMB 车用

SMBJ36A SMBJ36CA 600 36.0 1 40.00 44.20 1 58.1 10.4 SMB

S-SMBJ36A S-SMBJ36CA 600 36.0 1 40.00 44.20 1 58.1 10.4 SMB 车用

SMBJ40A SMBJ40CA 600 40.0 1 44.40 49.10 1 64.5 9.3 SMB

SMBJ43A SMBJ43CA 600 43.0 1 47.80 52.80 1 69.4 8.7 SMB

SMBJ45A SMBJ45CA 600 45.0 1 50.00 55.30 1 72.7 8.3 SMB

SMBJ48A SMBJ48CA 600 48.0 1 53.30 58.90 1 77.4 7.8 SMB

SMBJ51A SMBJ51CA 600 51.0 1 56.70 62.70 1 82.4 7.3 SMB

SMBJ54A SMBJ54CA 600 54.0 1 60.00 66.30 1 87.1 6.9 SMB

SMBJ58A SMBJ58CA 600 58.0 1 64.40 71.20 1 93.6 6.4 SMB

SMBJ60A SMBJ60CA 600 60.0 1 66.70 73.70 1 96.8 6.2 SMB

S-SMBJ60A S-SMBJ60CA 600 60.0 1 66.70 73.70 1 96.8 6.2 SMB 车用

SMBJ64A SMBJ64CA 600 64.0 1 71.10 78.60 1 103.0 5.8 SMB

SMBJ70A SMBJ70CA 600 70.0 1 77.80 86.00 1 113.0 5.3 SMB

SMBJ75A SMBJ75CA 600 75.0 1 83.30 92.10 1 121.0 5.0 SMB

SMBJ78A SMBJ78CA 600 78.0 1 86.70 95.80 1 125.0 4.8 SMB

SMBJ85A SMBJ85CA 600 85.0 1 94.40 104.00 1 137.0 4.4 SMB

SMBJ90A SMBJ90CA 600 90.0 1 100.00 111.00 1 146.0 4.1 SMB

SMBJ100A SMBJ100CA 600 100.0 1 111.00 123.00 1 162.0 3.7 SMB

SMBJ110A SMBJ110CA 600 110.0 1 122.00 135.00 1 177.0 3.4 SMB

SMBJ120A SMBJ120CA 600 120.0 1 133.00 147.00 1 193.0 3.1 SMB

SMBJ130A SMBJ130CA 600 130.0 1 144.00 159.00 1 209.0 2.9 SMB

SMBJ150A SMBJ150CA 600 150.0 1 167.00 185.00 1 243.0 2.5 SMB

SMBJ160A SMBJ160CA 600 160.0 1 178.00 197.00 1 259.0 2.3 SMB

SMBJ170A SMBJ170CA 600 170.0 1 189.00 209.00 1 275.0 2.2 SMB

SMBJ180A SMBJ180CA 600 180.0 1 201.00 222.00 1 292.0 2.1 SMB

SMBJ190A SMBJ190CA 600 190.0 1 211.00 234.00 1 307.0 2.0 SMB

SMBJ200A SMBJ200CA 600 200.0 1 224.00 247.00 1 324.0 1.9 SMB

SMBJ210A SMBJ210CA 600 210.0 1 233.00 258.00 1 337.0 1.8 SMB

SMBJ220A SMBJ220CA 600 220.0 1 246.00 272.00 1 356.0 1.7 SMB

SMBJ250A SMBJ250CA 600 250.0 1 279.00 309.00 1 405.0 1.5 SMB

SMBJ300A SMBJ300CA 600 300.0 1 335.00 371.00 1 486.0 1.3 SMB

SMBJ350A SMBJ350CA 600 350.0 1 391.00 432.00 1 567.0 1.1 SMB

SMBJ400A SMBJ400CA 600 400.0 1 447.00 494.00 1 648.0 0.9 SMB

SMBJ440A SMBJ440CA 600 440.0 1 492.00 543.00 1 713.0 0.8 SMB

10BJ5.0A 10BJ5.0CA 1000 5.0 200 6.40 7.00 10 9.2 108.7 SMB

10BJ6.0A 10BJ6.0CA 1000 6.0 200 6.67 7.37 10 10.3 97.1 SMB

10BJ6.5A 10BJ6.5CA 1000 6.5 100 7.22 7.98 10 11.2 89.3 SMB

10BJ7.0A 10BJ7.0CA 1000 7.0 80 7.78 8.60 10 12.0 83.4 SMB

10BJ7.5A 10BJ7.5CA 1000 7.5 50 8.33 9.21 1 12.9 77.6 SMB

10BJ8.0A 10BJ8.0CA 1000 8.0 20 8.89 9.83 1 13.6 73.6 SMB

10BJ8.5A 10BJ8.5CA 1000 8.5 10 9.44 10.40 1 14.4 69.5 SMB

10BJ9.0A 10BJ9.0CA 1000 9.0 5 10.00 11.10 1 15.4 65.0 SMB

10BJ10A 10BJ10CA 1000 10.0 2 11.10 12.30 1 17.0 58.9 SMB

10BJ11A 10BJ11CA 1000 11.0 1 12.20 13.50 1 18.2 55.0 SMB

10BJ12A 10BJ12CA 1000 12.0 1 13.30 14.70 1 19.9 50.3 SMB

10BJ13A 10BJ13CA 1000 13.0 1 14.40 15.90 1 21.5 46.6 SMB

10BJ14A 10BJ14CA 1000 14.0 1 15.60 17.20 1 23.2 43.1 SMB

10BJ15A 10BJ15CA 1000 15.0 1 16.70 18.50 1 24.4 41.0 SMB

10BJ16A 10BJ16CA 1000 16.0 1 17.80 19.70 1 26.0 38.5 SMB

10BJ17A 10BJ17CA 1000 17.0 1 18.90 20.90 1 27.6 36.3 SMB

10BJ18A 10BJ18CA 1000 18.0 1 20.00 22.10 1 29.2 34.3 SMB

10BJ20A 10BJ20CA 1000 20.0 1 22.00 24.50 1 32.4 30.9 SMB

10BJ22A 10BJ22CA 1000 22.0 1 24.40 26.90 1 35.5 28.2 SMB

10BJ24A 10BJ24CA 1000 24.0 1 26.70 29.50 1 38.9 25.7 SMB

S-10BJ24A S-10BJ24CA 1000 24.0 1 26.70 29.50 1 38.9 25.7 SMB 车用

10BJ26A 10BJ26CA 1000 26.0 1 28.90 31.90 1 42.1 23.8 SMB

10BJ28A 10BJ28CA 1000 28.0 1 31.30 34.40 1 45.4 22.1 SMB

10BJ30A 10BJ30CA 1000 30.0 1 33.30 36.80 1 48.4 20.7 SMB

10BJ33A 10BJ33CA 1000 33.0 1 36.70 40.60 1 53.3 18.8 SMB

S-10BJ33A S-10BJ33CA 1000 33.0 1 36.70 40.60 1 53.3 18.8 SMB 车用

10BJ36A 10BJ36CA 1000 36.0 1 40.00 44.20 1 58.1 17.3 SMB

S-10BJ36A S-10BJ36CA 1000 36.0 1 40.00 44.20 1 58.1 17.3 SMB 车用

10BJ40A 10BJ40CA 1000 40.0 1 44.40 49.10 1 64.5 15.5 SMB

10BJ43A 10BJ43CA 1000 43.0 1 47.80 52.80 1 69.4 14.4 SMB

10BJ45A 10BJ45CA 1000 45.0 1 50.00 55.30 1 72.7 13.8 SMB

10BJ48A 10BJ48CA 1000 48.0 1 53.30 58.90 1 77.4 13.0 SMB

10BJ51A 10BJ51CA 1000 51.0 1 56.70 62.70 1 82.4 12.2 SMB

10BJ54A 10BJ54CA 1000 54.0 1 60.00 66.30 1 87.1 11.5 SMB

10BJ58A 10BJ58CA 1000 58.0 1 64.40 71.20 1 93.6 10.7 SMB

10BJ60A 10BJ60CA 1000 60.0 1 66.70 73.70 1 96.8 10.4 SMB

S-10BJ60A S-10BJ60CA 1000 60.0 1 66.70 73.70 1 96.8 10.4 SMB 车用

10BJ64A 10BJ64CA 1000 64.0 1 71.10 78.60 1 103.0 9.7 SMB

10BJ70A 10BJ70CA 1000 70.0 1 77.80 86.00 1 113.0 8.9 SMB

10BJ75A 10BJ75CA 1000 75.0 1 83.30 92.10 1 121.0 8.3 SMB

10BJ78A 10BJ78CA 1000 78.0 1 86.70 95.80 1 126.0 8.0 SMB

10BJ85A 10BJ85CA 1000 85.0 1 94.40 104.00 1 137.0 7.3 SMB

10BJ90A 10BJ90CA 1000 90.0 1 100.00 111.00 1 146.0 6.9 SMB

10BJ100A 10BJ100CA 1000 100.0 1 111.00 123.00 1 162.0 6.2 SMB

10BJ110A 10BJ110CA 1000 110.0 1 122.00 135.00 1 177.0 5.7 SMB

10BJ120A 10BJ120CA 1000 120.0 1 133.00 147.00 1 193.0 5.2 SMB

10BJ130A 10BJ130CA 1000 130.0 1 144.00 159.00 1 209.0 4.8 SMB

10BJ150A 10BJ150CA 1000 150.0 1 167.00 185.00 1 243.0 4.2 SMB

10BJ160A 10BJ160CA 1000 160.0 1 178.00 197.00 1 259.0 3.9 SMB

10BJ170A 10BJ170CA 1000 170.0 1 189.00 209.00 1 275.0 3.7 SMB

10BJ180A 10BJ180CA 1000 180.0 1 201.00 222.00 1 292.0 3.5 SMB

10BJ190A 10BJ190CA 1000 190.0 1 211.00 234.00 1 307.0 3.3 SMB

10BJ200A 10BJ200CA 1000 200.0 1 224.00 247.00 1 324.0 3.1 SMB

SMB15J28A SMB15J28CA 1500 28.0 1 31.10 34.40 1 45.4 33.1 SMB

SMB15J30A SMB15J30CA 1500 30.0 1 33.50 36.80 1 48.4 31.0 SMB

SMB15J33A SMB15J33CA 1500 33.0 1 36.70 40.60 1 53.3 28.2 SMB

SMB15J36A SMB15J36CA 1500 36.0 1 40.00 44.20 1 58.1 25.9 SMB

SMB30J28A SMB30J28CA 3000 28.0 5 31.10 34.40 1 45.4 66.1 SMB

SMB30J30A SMB30J30CA 3000 30.0 5 33.50 36.80 1 48.4 62.0 SMB

SMB30J33A SMB30J33CA 3000 33.0 5 36.70 40.60 1 53.3 56.3 SMB

SMB30J36A SMB30J36CA 3000 36.0 5 40.00 44.20 1 58.1 51.6 SMB

SMB30J40A SMB30J40CA 3000 40.0 5 44.40 49.10 1 64.5 46.5 SMB
